Product Model |
DL4 65WE Basic G2 |
DL6 100WE Basic G2 |
DL4 65WE 3CCT G2 |
DL6 100WE 3CCT G2 |
|
BOM Code |
107630 |
107631 |
107632 |
107633 |
|
Operating Voltage |
120V(108-132VAC) |
120V(108-132VAC) |
120V(108-132VAC) |
120V(108-132VAC) |
|
Operating Frequency |
60Hz |
60Hz |
60Hz |
60Hz |
|
Input Power ±10% |
8.6W |
12.5W |
8.6W |
12.5W |
|
Power factor |
0.7 |
0.7 |
0.7 |
0.7 |
|
Luminous flux ±10% |
650 |
950 |
650 |
950 |
|
Efficacy ±10% |
75 |
75 |
75 |
75 |
|
CRI(Ra)&CCT |
827/830/840/850 |
827/830/840/850 |
830/840/850 |
830/840/850 |
|
Operating Temp. |
-20/+40 °C |
-20/+40 °C |
-20/+40 °C |
-20/+40 °C |
|
Base(Cap) |
E26 |
E26 |
E26 |
E26 |
|
Dimensions |
Φ128*51 |
Φ185*48 |
Φ128*51 |
Φ185*48 |
|
Driver |
IC |
IC |
IC |
IC |
|
Dimmable |
DIM |
DIM |
DIM |
DIM |
|
Certification |
UL/ES |
UL/ES |
UL/ES |
UL/ES |
|
Beam Angle(±10%) |
85° |
90° |
85° |
90° |
|
Lifetime (70% lumen ) |
35000hrs |
35000hrs |
35000hrs |
35000hrs |
